Major TechMTD73A True RMS 800A AC Clamp Meter
R739
About
The MTD73A True RMS 800A AC Clamp Meter is a useful tool that allows you to safely test for electrical problems, motor’s condition and current on appliances. Equipped to test any electrical circuit without disconnecting any wires. Handy function includes a backlit LCD display and Flashlight for working in dimly lit areas. The NCV Non-Contact Voltage detector is useful for a quick check to see it voltage is present on circuit under test. Measures 0.001A to 800A AC, 0.1mV to 600V AC/DC, Temperature, Capacitance, Frequency, Resistance, Continuity buzzer and Diode Test. This 800A AC Clamp Meter has a 28mm Jaw opening and accessories include test leads, temperature air probe and carrying case.
Product Features
- Measures AC Current, AC Voltage, DC Voltage, Temperature, Capacitance, Frequency and Resistance
- Measures AC current to 800 Amps without breaking the circuit
- Resolution to 100mA AC Current
- 28mm conductor size
- 4000 count LCD display with backlight
- Continuity and buzzer test
- Data hold and Duty Cycle function
- Auto power off
- Low battery indication
- CAT III 600V
Product Specifications
- Includes:
- Carrying case
- Test leads
- Air temperature probes
- Instruction manual
- Dimensions: 185 x 65 x 37mm
- Weight: 180g
- Power source: 2 x 1.5V AAA batteries (not included)
- DC Voltage: 400mV – 4V – 40V – 400V – 600V
- DC Voltage accuracy: ±(0.5% + 5d)
- AC Voltage: 4V – 40V – 400V – 600V
- AC voltage accuracy: ±(1.0% +5)
- AC Current: 4A – 40A – 400A – 800A
- AC Current accuracy: ±(3.0% +5)
- Resistance: 400Ω – 4kΩ – 40kΩ – 400kΩ – 4MΩ – 40MΩ
- Resistance accuracy: ±(0.8% + 3d)
- Capacitance: 4nF – 40nF – 400nF – 4uF – 40uF – 400uF – 4mF – 40mF
- Capacitance accuracy: ±(2.5% + 5d)
- Frequency: 10Hz – 100Hz – 1kHz – 10kHz – 100kHz – 1MHz – 10MHz
- Frequency accuracy: ±(0.5% + 4d)
- Temperature: -40 to 1000°C
- Temperature accuracy: ±(1.0% + 5°C)
- Continuity: Buzzer sounds at approx. 50Ω
- Diode Test: Test current 0.8mA, open circuit voltage 2.2V
- Warranty: 12 months
