HisenseRAC DC Air-Conditioning Unit with Inverter

Please Note

• To maintain the warranty of this product, the unit needs to be installed by a Hisense Accredited Installer (made available on Hisense's website)

About

Ultra-Wide Frequency Control (10~150Hz)

With ultra-wide frequency control technology, AC intelligently regulates operating frequency according to the temperature variation of the environment. Control is more accurate (±0.5°C) to prevent the room temperature from fluctuating and ultimately keep you comfortable.

Fast Cooling

The unique weak magnetic control technology is used to operate at high frequency under high-temperature ambience, which achieves greater cooling capacity and increases the cooling rate by 25%.

Intellegent Wifi Control
Conveniently control your AC from anywhere in your home using a Wi-Fi connection and your mobile phone. This feature does not come standard, should you want to enable it, please contact us to set it up.

Voltage Mutation Self-adaptive

With voltage supply variances from 150 V to 264 V the system will continue to operate stably due to the unique voltage mutation self-adaptive technology. This will
effectively solve the voltage variances and improve stability of the system's operation which in turn protects the system from failure.

Ultra Quiet

Based on the principles of airflow and acoustics, we were able to optimize the structure of the inner air duct to reduce noise. Our technology effectively eliminates noise interference and allows your family to sleep undisturbed when operating at night.

High Efficiency & Energy Saving

By using 3D inverter technology, combined with an optimised inner air duct and an advanced inner-grooved tube and louvre fin, the AC gains a significant boost in energy efficiency that reduces your annual power consumption by 30%.

Product Features

• Ultra-Wide Frequency Control
• Ultra Quiet
• High Efficiency and Energy Saving
• Fast Cooling
• LED Display on Front Panel
• LCD Wireless Remote Controller
• Removable and washable Panel
• Optional Active Charcoal Filter
• Optional Electrostatic Filter
• Optional LTC Filter
• Optional Catechin filter
• Optional Negative ion filter
• Optional Photic Catalyst filter
• Optional Vitamin-C filter
• Dimmer
• 24 Hours Timer
• Timer ON/OFF
• 5 Speed and Auto Indoor Fan Control
• Silent Mode
• Horizontal Auto Swing Louver
• Manual Adjustable Vertical Louver
• Top-Down Horizontal louvres features for cooling mode
• Sleep function
• Smart sense function
• Super function
• Compressor Indicator
• Auto Restart
• Auto Defrost
• Dehumidification function
• Cold air protection
• Warranty: 1 year on the unit & 3 years on the compressor.

Product Specifications

 9000 BTU

• Cooling Capacity:  2640 (900-3300)
• Heating Capacity: 2745(1100-2800)
• Power Input-Cooling:  810(200-1200)
• Power Input-Heating:  760(300-1000)
• Air Circulation: 550
• EER: 3.25925925925926
• COP: 3.61184210526316
• Moisture Removal: 0.9
• Energy Class for Argentina (Cooling): A
• Energy Class for Argentina (Heating): A+
• Refrigerant: R410A
• Refrigerant volume: 610
• Unit Noise Level: INDOOR: (HIGH) = 39, (LOW) = 30 / OUTDOOR: 54

System

• Compressor type: Rotary
• Compressor Model No: QA108MJA
• Compressor MFG: LG
• Expansion Device: flow restrictor
• Evaporator: Copper tube and Aluminum Fin
• Condenser: Copper tube and Aluminum Fin

Connecting Pipe Diameter

• Liquid Pipe (inch): 1/4
• Gas Pipe (inch): 3/8
• Maximum connection pipe length: 15
• Maximum height difference: 5

Filter information

• Washable PP filter: Yes
• HEPA Filter: Optional

Dimensions W x H x D (mm):

• Indoor Unit: 850×270×202
• Net Weight: 8.5kg
• Outdoor Unit: 715×482×240
• Net weight: 27kg

 18000 BTU

System

• Compressor type: Rotary
• Compressor Model No.: ATN150D42UFZ
• Compressor MFG: GMCC
• Expansion Device: Flow restrictor
• Evaporator: Copper tube and Aluminum Fin
• Condenser: Copper tube and Aluminum Fin

Connecting Pipe Diameter

• Liquid Pipe (inch): 1/4
• Gas Pipe (inch): 1/2
• Maximum connection pipe length: 15
• Maximum height difference: 5

Filter information

• Washable PP filter: Yes
• HEPA Filter: Optional

Dimensions W x H x D (mm):

• Indoor Unit: 960×315×230
• Net Weight: 12.5
• Outdoor Unit: 810x585x280
• Net weight: 39kg

22000 BTU

Ratings

• Cooling Capacity: 6500（2300-7900）
• Heating Capacity: 6600(2100-9000)
• Power Input-Cooling: 1980(600-3000)
• Power Input-Heating: 1920(600-3300)
• Moisture Removal: 2.5
• Air Circulation: 1150
• EER: 3.28282828282828
• COP: 3.4375
• Energy Class for Argentina (Cooling): A
• Energy Class for Argentina (Heating): A+
• Refrigerant: R410A
• Refrigerant column: 1670
• Unit Noise Level: INDOOR: (HIGH) = 48, (LOW) = 40 / OUTDOOR: 58

• Voltage, Frequency, Phase: 220-240V~,50Hz,1P
• Rated Current Cooling (A): 9.2
• Rated Current Heating (A): 8.9
• LRA: –

Connecting Pipe Diameter

• Liquid Pipe (inch): 3/8
• Gas Pipe (inch): 5/8
• Maximum connection pipe length: 15
• Maximum height difference: 5

Dimensions W x H x D (mm):

• Indoor Unit: 1131×315×230
• Net Weight: 124.5
• Outdoor Unit: 860x650x310
• Net weight: 47kg
